HR-A Series Rack-Mounted Online UPS 6-10KVA

FEATURES

19 inches standard design of rack mount,compact structure.
Sine wave output provides best power supply guarantee.
0 conversion time between mains mode and battery mode.
It has detection function of input zero line and fire line.
Having voltage surge protection function and strong anti-interference function.
Equipped with correction function of input power factor
Supporting mobile smart monitoring card ,users can real-time monitor every data of the UPS by mobile APP.

Model	HR-A 6K	HR-A 6KL	HR-A 10K	HR-A 10KL
Rated Power	6KVA/5.4KW		10KVA/9KW
INPUT
Voltage Range	120-275Vac 1P2W+G
Working Frequency Range	40-70Hz (settable)
Input Power Factor	≥0.99
OUTPUT
Rated Voltage and Accuracy	220Vac(1±1%) 1P2W+G
Output Frequency	46-54Hz synchronize with mains power;
Output Frequency	50Hz (Mains power between 40-46Hz and 54-60Hz ); 50Hz (Battery).
Rated Current	27A		45A
Output Power Factor	0.9
Output Harmonic Wave	≤3%（Full R Load）
Crest Factor	03:01:00
Output Overload （Normal Mode）	105%±5%＜Load≤125%±5%: Convert to bypass output and alarm after 1 min.
	125%±5%＜Load≤135%±5%: Convert to bypass output and alarm after 30s.
	Load＞135%±5%: Convert to bypass output and alarm after 300ms.
Transfer Time	0 ms (Normal mode ← → Battery Mode)
Efficiency	＞92%
BATTERY
Rated Voltage	192VDC
Quantity	Internal	External	Internal	External
Quantity	16*12V7AH	External	16*12V7AH	External
Charging Current	1A	5.5A	1A	5.5A
Dimension (LxWxH) mm	665482.6132.5
Weight	19KG	20KG	20.5KG	21.5KG
Working Temperature	0℃〜40℃
Working Humidity	20%〜95％（non-condensing）
Noise	≤55dB
* Product specifications are subject to change without further notice.
